Camera Image Sensor: 1/2.7″ Progressive Scan CMOS Max. Resolution: 1920 ? 1080 Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR Shutter Time: 1/3 s to 1/100,000 s Day & Night: IR Cut Filter Angle Adjustment: Pan: 0? to 360?, tilt: 0? to 90?, rotate: 0? to 360? Lens Focus: Fixed Focal Length & FOV 2.8 mm: horizontal FOV 111.6?, vertical FOV 59.1?, diagonal FOV 133.9? 4 mm: horizontal FOV 91.5?, vertical FOV 46.1?, diagonal FOV 109.8? 6 mm: horizontal FOV 56?, vertical FOV 29.8?, diagonal FOV 65.3? Lens Mount: M12 Aperture: F1.6 Illuminator Supplement Light Type: IR Supplement Light Range: Up to 30 m IR Wavelength: 850 nm Video Main Stream 50 Hz: 25 fps (1920 ? 1080, 1280 ? 720) 60 Hz: 30 fps (1920 ? 1080, 1280 ? 720) Sub-Stream 50Hz: 25 fps (640 ? 480, 640 ? 360) 60Hz: 30 fps (640 ? 480, 640 ? 360) Video Compression Main stream: H.265 /H.265/H.264 /H.264 Sub-stream: H.265/H.264/MJPEG Video Bit Rate: 32 Kbps to 8 Mbps H.264 Type: Baseline Profile/Main Profile/High Profile H.265 Type: Main Profile Region Of Interest (ROI): Support 1 fixed region for main stream Network Simultaneous Live View: Up to 6 channels API: Open Network Video Interface, ISAPI User/Host: Up to 32 users. 3 levels: administrator, operator and user Network Storage: Support Micro SD/SDHC/SDXC card (256 GB), local storage and NAS (NFS, SMB/CIFS), ANR Client: iVMS-4200, Hik-Connect, Hik-Central Web Browser Plug-in required live view: IE 10 Plug-in free live view: Chrome 57.0 , Firefox 52.0 Local service: Chrome 57.0 , Firefox 52.0 Image Image Settings: Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser Day/Night Switch: Day, Night, Auto, Schedule Image Enhancement: BLC, 3D DNR Wide Dynamic Range (WDR): 120 dB Interface Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port On-Board Storage: Built-in Micro SD slot, up to 256 GB Reset Key Yes Event Smart Event: Line crossing detection, intrusion detection Linkage: Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture General Power 12 VDC ? 25%, 0.4 A, max. 5 W, ?5.5 mm coaxial power plug PoE: 802.3af, Class 3, 36 to 57 V, 0.2 A to 0.15 A, max. 6.5 W Material: Metal, Plastic Dimension: 69.7 mm ? 67.9 mm ? 171.4 mm (2.7″ ? 2.7″ ? 6.7″) Package Dimension: 216 mm ? 121 mm ? 118 mm (8.5″ ? 4.8″ ? 4.7) Weight: Approx. 350 g (0.8 lb.) With Package Weight: Approx. 450 g (1.0 lb.) Storage Conditions: -30 ?C to 60 ?C (-22 ?F to 140 ?F). Humidity: 95% or less (non-condensing) Startup And Operating Conditions: -30 ?C to 60 ?C (-22 ?F to 140 ?F). Humidity: 95% or less (non-condensing) Language 33 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian General Function: One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter Approval EMC: FCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) Safety: UL (UL 60950-1); CB (IEC 60950-1:2005 Am 1:2009 Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 60950-1:2005 Am 1:2009 Am 2:2013, IEC 62368-1:2014); BIS (IS 13252(Part 1):2010 A1:2013 A2:2015); LOA (IEC/EN 60950-1) Environment: CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) ProtectionIP67 (IEC 60529-2013) SKU: DS-2CD2021G1-I28MM Category: CCTV & Security
